22 GESTALT X10 50CM
$2,199.00
Out of Stock
Super Fast Nationwide Shipping! View Shipping Information
Description
The Gestalt is for the drop bar rider that doesn’t want to stick to pavement, and can’t help but get dirty no matter the route. Long distance commuters and all-weather riders will appreciate the fender and rack mounts and the sure stopping disc brakes, and the larger volume tires are right at home on that unexpected detour.
| 50 | 52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|
| STACK | 542.5 | 560.4 | 574.7 | 593.7 | 612.7 | 633.8 |
| REACH | 369.6 | 374.3 | 374.8 | 389.1 | 397.7 | 406.2 |
| HEADTUBE ANGLE | 71° | 72° | 72° | 72° | 72° | 72.5° |
| HEADTUBE LENGTH | 120 | 135 | 150 | 170 | 190 | 210 |
| SEATTUBE ANGLE | 74.5° | 74° | 73.5° | 73.5° | 73° | 73° |
| SEATTUBE LENGTH | 470 | 490 | 510 | 530 | 550 | 570 |
| TOPTUBE EFFECTIVE | 520 | 535 | 545 | 565 | 585 | 600 |
| BB HEIGHT | 271 | 271 | 271 | 271 | 271 | 271 |
| BB DROP | 72 | 72 | 72 | 72 | 72 | 72 |
| CHAINSTAY | 415 | 415 | 415 | 415 | 415 | 415 |
| WHEELBASE | 993.1 | 994.3 | 999.4 | 1019.9 | 1034.6 | 1044.5 |
| STANDOVER HEIGHT | 713 | 732 | 751 | 774 | 793 | 813 |
| FORK OFFSET | 50 | 50 | 50 | 50 | 50 | 50 |
| SEATPOST DIAMETER | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
| HANDLEBAR WIDTH | 400 | 400 | 420 | 420 | 440 | 440 |
| STEM LENGTH | 70 | 70 | 90 | 90 | 110 | 110 |
| CRANK LENGTH | 170 | 170 | 175 | 175 | 175 | 175 |
| 01. FRAME | Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle |
| 02. FORK | Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets |
| 03. RIMS | Marin Aluminum Double Wall, 19mm Inner, 24mm Tall, Disc Specific |
| 04. HUB, REAR | Forged Aluminum Alloy, 32H |
| 05. HUB, FRONT | Forged Aluminum Alloy, 32H |
| 06. SPOKE, NIPPLES | 14g Black Stainless Steel |
| 07. TIRES | Schwalbe G-One Performance, 700Cx40mm, Folding Bead |
| 08. DERAILLEUR, REAR | MicroSHIFT Advent X 10-Speed Wide-Range |
| 10. SHIFT LEVER | MicroSHIFT Advent X 10-Speed |
| 11. CRANKSET | Forged Alloy 1x10, Hollow CrMo Spindle, Narrow Wide 42T |
| 12. BOTTOM BRACKET | External Sealed Cartridge Bearings |
| 13. CHAIN | KMC X10 |
| 14. CASSETTE | SunRace 10-Speed, 11-51T |
| 15. BRAKE, FRONT | Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor |
| 16. BRAKE, REAR | Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor |
| 17. BRAKE LEVERS | MicroSHIFT Advent X |
| 18. HANDLEBAR | Marin Butted Alloy, Compact 16º Flared Drop |
| 19. STEM | Marin 3D Forged Alloy |
| 20. GRIPS | Marin Shock Absorbing Perforated Tape |
| 21. HEADSET | FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2” |
| 22. SEATPOST | Marin Alloy, 27.2mm |
| 23. SADDLE | Marin Beyond Road Concept |
| 24. EXTRAS | Bolt-On Thru-Axles F and R |
Additional Information
| Size | Xs |
|---|
