Description
FITNESS ROAD RIDING
COMMUTING
BIKE PATH RIDING
The Fairfax and Terra Linda make up our Fitness line, built for the flat-bar fitness road rider with the accessory mounts and gear range for future upgrades.
- Frame Series 3 Fitness, 6061 Aluminum, 700C Wheels, Relieved Tapered Head Tube and BB, Internal Cable Routing, Disc Specific Forged Dropouts, Fender, Rack, and Kickstand Mounts
- Fork Marin Full Carbon w/Tapered Steerer, Fender Eyelets
- Rims Marin Aluminum Double Wall, 19mm ID, 25mm Tall, Disc Specific
- Hubs Forged Aluminum Alloy, Disc, 32H
- Spokes 14g Black Stainless Steel
- Tires Vee Tire, G-Sport, 700Cx35mm, Puncture Protection, Wire Bead
- Bottom Bracket Sealed Cartridge Bearings, Square Taper
- Crankset Forged Alloy, 48/32T Chainrings, Ring Guard
- Shifters MicroSHIFT R9 2x9 Flat Bar Road Shifters
- Front Derailleur MicroSHIFT R9
- Rear Derailleur Shimano Sora
- Cassette/Freewheel Shimano, 9-Speed, 11-34T
- Chain KMC X9
- Brakes Tektro HDM275 Hydraulic Disc, 160mm Rotor
- Brake Levers Tektro Hydraulic
- Handlebars Marin Alloy Flat
- Tape/Grips Marin Ergonomic Locking
- Stem Marin 3D Forged Alloy
- Headset FSA, No.42/CB
- Seatpost Marin Alloy, 27.2mm
- Saddle Marin Fitness Plush
- Pedals Commute Platform
* Subject to change without notice.
| Size | X-Small | Small | Medium | Large | X-Large |
|---|---|---|---|---|---|
| A STACK (mm) | 557 | 571.3 | 590 | 609 | 637.3 |
| B REACH (mm) | 385 | 400 | 420 | 440 | 455 |
| C HEADTUBE ANGLE | 70.5° | 70.5° | 70.5° | 70.5° | 70.5° |
| D HEADTUBE LENGTH (mm) | 140 | 155 | 175 | 195 | 225 |
| E SEATTUBE ANGLE | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| F SEATTUBE LENGTH (mm) | 380 | 430 | 480 | 520 | 550 |
| G TOPTUBE EFFECTIVE (mm) | 550 | 569.2 | 594.8 | 620.4 | 643.8 |
| H BB HEIGHT (mm) | 283.5 | 283.5 | 283.5 | 283.5 | 283.5 |
| I BB DROP (mm) | 70 | 70 | 70 | 70 | 70 |
| J CHAINSTAY (mm) | 445 | 445 | 445 | 445 | 445 |
| K WHEELBASE (mm) | 1050.01 | 1070 | 1096.7 | 1123.4 | 1148.4 |
| L STANDOVER HEIGHT (mm) | 660.74 | 705.38 | 745.2 | 780.34 | 809.68 |
| M FORK OFFSET (mm) | 50 | 50 | 50 | 50 | 50 |
| SEATPOST DIAMETER (mm) | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
| HANDLEBAR WIDTH (mm) | 640 | 640 | 680 | 680 | 680 |
| STEM LENGTH (mm) | 70 | 70 | 70 | 70 | 70 |
| CRANK LENGTH (mm) | 170 | 170 | 175 | 175 | 175 |
Additional Information
| Size | Md |
|---|
